Regenerative turbine pump Speck Pumpen Y-1638-MM
APPLICATION
Medical engineering.
Cooling of medical lasers.
Temperature control / Industrial cooling.
Cooling of machines, systems and production processes.
Cooling in the semiconductor industry.
Cooling of industrial lasers.
Temperature control of control cabinets.
Temperature control in laboratory applications.
Railcars. Delivery of drinking water and service water in train wagons.
Technical parameters
Model: Y-1638-MM
Series: Y
Pumped medium: Water – max.80°C
Water/glycol-mixture - max.80°C
Water/glycol-mixture - max.80°C
Engine: 24V, max.180W, 2000-6000 1/min, EC
Realization
Material: Stainless steel, Plastics
Pressure line: G 1/4
Input line: G 1/4
Seal type: Separating can / Canned motor
Size: 106 x 92 x 151 mm
Description:
Close-coupled pumps with EC motor
- Canned motor
- Parameters set by the manufacturer
- Power consumption depending on load and speed
- Within the displayed characteristic curve every operating point can be selected by parameterizing the drive accordingly
Compact design
Steep characteristic curve
Long service life due to sealless version and bearingless motor
