Centrifugal pump Speck Pumpen MU025160-MK-PM
Technical parameters
Model: MU025160-MK-PM
Series: MU.. -MK-PM
Pumped medium: Version spheroidal graphite cast iron:
Water max. 160°C
Oil - 40°C - +300°C (higher temperatures on request)
Version stainless steel:
Water max. 160°C
Oil -100°C - +300°C (higher temperatures on request)
Water max. 160°C
Oil - 40°C - +300°C (higher temperatures on request)
Version stainless steel:
Water max. 160°C
Oil -100°C - +300°C (higher temperatures on request)
Engine: PM synchronous motor (VSD)
1.5 kW – 5.3 kW
3~Mot
1000-4000 1/min
1.5 kW – 5.3 kW
3~Mot
1000-4000 1/min
Realization
Material: Stainless steel, Spheroidal graphite cast iron
Pressure line: G 1 / SAE 1
Input line: G 1 1/2 / SAE 1 1/2
Seal type: Magnetic drive
Size: 214-247 x 245-305 x 457-568
Description:
Close-coupled pumps with magnetic coupling
- Operation with frequency converter only
- Within the displayed characteristic curve every operating point can be selected by parameterizing the drive accordingly
- Power consumption depending on load and speed
Compact design
Leakage-free and maintenance-free due to magnetic coupling
High motor efficiency
