Heat transfer pumps with mechanical seal

Model: TOEGN, TOEGA, TOEGI

Series: TOEGN, TOEGA, TOEGI

Pumped medium: Thermal oil 0 - 350°C
Water – max.160°C (max.180°C по запросу)

Engine: 50Hz: 2900 1/min,
max. 100 m / 540 m3/h
60Hz: 3500 1/min,
max.100 m / 460 m3/h

Material: Spheroidal graphite cast iron

Pressure line: DN32-DN125

Input line: DN50-DN150

Seal type: Mechanical seal

TOE-GA-40-160
TOE-GA-100-200
TOE-GI-40-160

Request a price

Heat transfer pumps with mechanical seal

Interchangeability of many parts at all series
Same hydraulics for TOEGN, TOEGA, TOEMN & TOEMA series
Same hydraulics for TOEGI and TOEMI series
Synthetic heat transfer media with low viscosities are delivered without any problems up to 350 °C
Hydrodynamically lubricated sleeve bearing in SiC
Low-wear impeller side chamber
